316 Stainless Steel Flange

A flange is a component that connects shafts to each other and is used for connecting pipe ends; Also used for flanges on equipment imports and exports, used for connecting two devices, such as gearbox flanges.

Quick Quote

Request A Sample

PRODUCTS

FOUR REASONS TO CHOOSE US

AAA Level
Credit Steel Supplier

15+
Stock Warehouses

Support
Three-party Inspection

Large Order
Preferential Policies

Order Now：sales1@xcbmetals.com

Product Description 316 Stainless Steel Flange

Product Parameters

Product Name	316 Stainless Steel Flange
Type	Elbow, Tee, Reducer, Tube cap, Flange, etc.
Material	Stianless Steel
Grade	Stainless steel 304 / 304L / 310S / 316L / 316Ti / 316LN / 317L / 904L / 2205 / 2507 / 32760 / 253MA / 254SMo / XM-19 / S31803 / S32750 / S32205 / F50 / F60 / F55 / F60 / F61 / F65 etc
Application	Chemical, Pharmaceutical & Bio-Medical, Petrochemical & Refinery, Environmental, Food Processing, Aviation, Chemical Fertilizer, Sewage Disposal, Desalination, Waste Incineration etc.
Delivery Time	7-40 days
Packaging	Waterproof polybag, wooden box
Payment	T/T, L/C,D/A,D/P, Western Union,MoneyGram,According to customer requirements payments for offline orders.
Sample	Free

Chemical Composition

Grade	C	Si	Mn	p	S	Ni	Cr	Mo	N
254SMO	≤0 .02	≤0.8	≤1.0	≤0.04	≤ 0.03	17.5-18.5	19.5-20.5	6.0-6.5	0.18-0.20
904L	≤0 .02	≤1.0	≤2.0	≤0.045	≤0.035	23.0-28.0	19.0-23.0	4.0-5.0	≤0.1
654SMO	≤0 .02	≤0 .5	2.0-4.0	≤0.03	≤0.005	21.0-23.0	24.0-25.0	7.0-8.0	0.45-0.55
253MA	0.05-0.1	1.4-2.0	-	≤0.045	≤ 0.03	10.0-12.0	20.0-22.0	-	0.14-0.20
AL-6XN	≤0 .02	≤1.0	≤2.0	≤0.04	≤ 0.01	23.5-25.5	20.0-22.0	6.0-7.0	0.18-0.25
304	≤0 .08	≤1.0	≤2.0	≤0.045	≤ 0.03	8.0-10.5	18.0-20.0	-	-
304L	≤0.03	≤1.0	≤2.0	≤0.035	≤ 0.03	9.0-13.0	18.0-20.0	-	-
309S	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	12.0-15.0	22.0-24.0	-	-
310S	≤0.08	≤1.5	≤2.0	≤0.035	≤ 0.03	19.0-22.0	24.0-26.0	-	-
316	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	10.0-14.0	16.0-18.0	2.0-3.0	-
316L	≤0 .03	≤1.0	≤2.0	≤0.045	≤ 0.03	12.0-15.0	16.0 -18.0	2.0 -3.0	-
S32760	≤ 0 .03	≤1.0	≤1.0	≤0.035	≤ 0.015	6.0-8.0	24.0 -26.0	3.0-4.0	0.2-0.3
S32750	≤ 0 .03	≤0.8	≤1.2	≤0.035	≤0.02	6.0-8.0	24.0-26.0	2.0-3.0	0.24-0.32

Mechanical Properties

Grade	State	Hardness HV	Yield Strength	Tensile Strength	Elongation(%)
SUS304	ANN	<200	>205	>520	>40
	1/4H	200-250	>255	>550	>35
	1/2H	250-310	>470	>780	>6
	3/4H	310-370	>665	>930	>3
	H	370-430	>880	>1130	--
SUS301	ANN	<250	>205	>520	>40
	1/4H	250-310	>470	>780	>35
	1/2H	310-370	>510	>930	>10
	3/4H	370-430	>745	>1130	>5
	H	430-490	>1030	>1320	>3
	EH	490-550	>1275	>1570	--
	SH	>550	>1500	>1850	--
SUS201	ANN	<200	>205	>515	>40
	1/4H	200-250	>250	>550	>35
	1/2H	250-310	>470	>780	>6
	3/4H	310-370	>665	>930	>3
	H	370-430	>880	>1130	--
SUS430	ANN	<200	>205	>450	>22
	1/2H	200-250	>330	>505	>10
	H	250-310	>420	>750	>6
SUS443	ANN	<200	>305	>483	>31
SUS310S	≤200	<200	>205	>520	>40
SUS316L	≤200	<200	>310	>620	>40
